python openCV自制绘画板

import numpy as np
import cv2
def nothing(x):
  pass
cv2.namedWindow(\'image\')
img = np.zeros((512,512,3),np.uint8)
cv2.createTrackbar(\'R\',\'image\',0,255,nothing)
cv2.createTrackbar(\'G\',\'image\',0,255,nothing)
cv2.createTrackbar(\'B\',\'image\',0,255,nothing)
drawing = False
mode = True
ix,iy = -1,-1
def drawing_fragment(event,x,y,flags,param):
  r = cv2.getTrackbarPos(\'R\',\'image\')
  g = cv2.getTrackbarPos(\'G\',\'image\')
  b = cv2.getTrackbarPos(\'B\',\'image\')
  color = (b,g,r)
  global drawing,ix,iy,mode
  if event == cv2.EVENT_LBUTTONDOWN:
    drawing = True
    ix = x
    iy = y
  elif event == cv2.EVENT_MOUSEMOVE:
    if drawing:
      if mode:
        cv2.rectangle(img,(ix,iy),(x,y),color,-1)
      else:
        cv2.circle(img,(x,y),5,color,-1)
  elif event == cv2.EVENT_LBUTTONUP:
    drawing = False

cv2.setMouseCallback(\'image\',drawing_fragment)
while True:
  cv2.imshow(\'image\',img)
  k = cv2.waitKey(2)
  if k == 27:
    break
  elif k == ord(\'q\'):
    mode = not mode
cv2.destroyAllWindows()
