Android如何实现年月选择器功能

开发过程中，年月的选择功能还是比较常见的，像这种功能点比较常见，要是每次都要自己手动去写，这无疑会耗费比较多的时间与精力，今天给大家介绍一个第三方库，使用该库来完成年月选择器功能。

一、效果图

Android如何实现年月选择器功能

二、实现步骤：

1、依赖库

implementation \'cn.aigestudio.wheelpicker:WheelPicker:1.1.3\'

2、xml布局文件

<?xml version=\"1.0\" encoding=\"utf-8\"?>
<android.support.constraint.ConstraintLayout xmlns:android=\"http://schemas.android.com/apk/res/android\"
 xmlns:app=\"http://schemas.android.com/apk/res-auto\"
 android:layout_width=\"match_parent\"
 android:layout_height=\"200dp\"
 android:background=\"#ffffff\">

 <TextView
  android:id=\"@+id/cancel\"
  android:layout_width=\"60dp\"
  android:layout_height=\"40dp\"
  android:gravity=\"center\"
  android:text=\"取消\"
  android:textColor=\"#666666\"
  android:textSize=\"17sp\"
  app:layout_constraintLeft_toLeftOf=\"parent\"
  app:layout_constraintTop_toTopOf=\"parent\" />

 <TextView
  android:id=\"@+id/ok\"
  android:layout_width=\"60dp\"
  android:layout_height=\"40dp\"
  android:gravity=\"center\"
  android:text=\"确定\"
  android:textColor=\"#3C76FF\"
  android:textSize=\"17sp\"
  app:layout_constraintRight_toRightOf=\"parent\"
  app:layout_constraintTop_toTopOf=\"parent\" />

 <View
  android:id=\"@+id/view_line\"
  android:layout_width=\"match_parent\"
  android:layout_height=\"1dp\"
  android:background=\"#e5e5e5\"
  app:layout_constraintLeft_toLeftOf=\"parent\"
  app:layout_constraintTop_toBottomOf=\"@id/cancel\" />

 <com.aigestudio.wheelpicker.WheelPicker
  android:id=\"@+id/mWheelPicker_1\"
  android:layout_width=\"0dp\"
  android:layout_height=\"0dp\"
  android:layout_marginLeft=\"30dp\"
  app:layout_constraintBottom_toBottomOf=\"parent\"
  app:layout_constraintLeft_toLeftOf=\"parent\"
  app:layout_constraintRight_toLeftOf=\"@id/mWheelPicker_2\"
  app:layout_constraintTop_toBottomOf=\"@id/view_line\"
  app:wheel_atmospheric=\"true\"
  app:wheel_curtain_color=\"#1886F7\"
  app:wheel_curved=\"true\"
  app:wheel_cyclic=\"true\"
  app:wheel_indicator_color=\"#e5e5e5\"
  app:wheel_item_text_color=\"#919191\"
  app:wheel_item_text_size=\"23sp\"
  app:wheel_selected_item_text_color=\"#000000\" />

 <com.aigestudio.wheelpicker.WheelPicker
  android:id=\"@+id/mWheelPicker_2\"
  android:layout_width=\"0dp\"
  android:layout_height=\"0dp\"
  android:layout_marginRight=\"30dp\"
  app:layout_constraintBottom_toBottomOf=\"parent\"
  app:layout_constraintLeft_toRightOf=\"@id/mWheelPicker_1\"
  app:layout_constraintRight_toRightOf=\"parent\"
  app:layout_constraintTop_toTopOf=\"@id/mWheelPicker_1\"
  app:wheel_atmospheric=\"true\"
  app:wheel_curtain_color=\"#1886F7\"
  app:wheel_curved=\"true\"
  app:wheel_cyclic=\"true\"
  app:wheel_indicator_color=\"#e5e5e5\"
  app:wheel_indicator_size=\"24sp\"
  app:wheel_item_text_color=\"#919191\"
  app:wheel_item_text_size=\"23sp\"
  app:wheel_selected_item_text_color=\"#000000\" />

</android.support.constraint.ConstraintLayout>

3、添加数据

 List<String> CEOYEAR = new ArrayList<>();
 List<String> CEOMONTH = new ArrayList<>();

 for (int i = 2000; i < 2051; i++) {
     CEOYEAR.add(i + \"\");
  }

 for (int i = 1; i < 13; i++) {
  CEOMONTH.add(i + \"\");
 }

4、设置选择器弹出框

 /**
  * @desc : 两个滚动器
  **/
 private void showTwoWheelPicker(Context context, final List<String> data1, final List<String> data2, final TwoWheelListener mTwoWheelListener) {

  final Dialog dialog = getDialog(context);
  Window window = dialog.getWindow();
  window.setGravity(Gravity.BOTTOM);
  window.setLayout(ViewGroup.LayoutParams.MATCH_PARENT, ViewGroup.LayoutParams.WRAP_CONTENT);
  window.setContentView(R.layout.fragment_sami);

  final WheelPicker wv1 = window.findViewById(R.id.mWheelPicker_1);
  final WheelPicker wv2 = window.findViewById(R.id.mWheelPicker_2);

  wv1.setData(data1);
  wv2.setData(data2);

  //取消
  window.findViewById(R.id.cancel).setOnClickListener(new View.OnClickListener() {
   @Override
   public void onClick(View v) {
    dialog.dismiss();
   }
  });

  //确定
  window.findViewById(R.id.ok).setOnClickListener(new View.OnClickListener() {
   @Override
   public void onClick(View v) {
    dialog.dismiss();

    if (mTwoWheelListener != null) {
     mTwoWheelListener.onOk(data1.get(wv1.getCurrentItemPosition()), data2.get(wv2.getCurrentItemPosition()));
    }
   }
  });
 }

 private Dialog getDialog(Context context) {

  return new AlertDialog.Builder(context, R.style.RoundCornerDialog).setCancelable(false).show();
 }

 private TwoWheelListener mTwoWheelListener = null;

 public static interface TwoWheelListener {
  void onOk(String str1, String str2);
 }

5、设置弹出框dialog样式

 <!--圆角的dialog样式-->
 <style name=\"RoundCornerDialog\" parent=\"@android:style/Theme.Dialog\">
  <item name=\"android:windowFrame\">@null</item>
  <item name=\"android:windowIsFloating\">true</item>
  <item name=\"android:windowIsTranslucent\">true</item>
  <item name=\"android:windowNoTitle\">true</item>
  <item name=\"android:background\">@android:color/transparent</item>
  <item name=\"android:windowBackground\">@android:color/transparent</item>
  <item name=\"android:backgroundDimEnabled\">true</item>
  <item name=\"android:backgroundDimAmount\">0.6</item>
</style>

6、设置点击事件弹出

 findViewById(R.id.btn).setOnClickListener(new View.OnClickListener() {
   @Override
   public void onClick(View v) {
    showTwoWheelPicker(AppBarLayoutActivity.this, CEOYEAR, CEOMONTH, new TwoWheelListener() {
     @Override
     public void onOk(String str1, String str2) {
      Toast.makeText(AppBarLayoutActivity.this, str1 + \"年\" + str2 + \"日\", Toast.LENGTH_SHORT).show();
     }
    });
   }
  });
